High-Horsepower street cars and trucks can be a challenge to keep cool. A proper cooling system starts with the right radiator. Aluminum Radiators cool more effectively and weigh less than older OEM style brass units.?
| Download Name | File Size |
| 199r10955.pdf | 173.95KB |
| 199r11914.pdf | 286.5KB |
| Make | Model | Submodel | Years | Engine |
| Chevrolet | Corvette | Base | 1977 | 5.7L / 350 / V8 |
| Chevrolet | Corvette | Base | 1978 | 5.7L / 350 / V8 |
| Chevrolet | Corvette | Base | 1979 | 5.7L / 350 / V8 |
| Chevrolet | Corvette | Base | 1980 | 5.7L / 350 / V8 5.0L / 305 / V8 |
| Chevrolet | Corvette | Base | 1981 | 5.7L / 350 / V8 |
| Chevrolet | Corvette | Base | 1982 | 5.7L / 350 / V8 |
| Chevrolet | Corvette | Collector's Edition | 1982 | 5.7L / 350 / V8 |
| Chevrolet | Corvette | Indianapolis 500 Pace Car | 1978 | 5.7L / 350 / V8 |
| Chevrolet | Corvette | Silver Anniversary Edition | 1978 | 5.7L / 350 / V8 |
| # of Passes | Single |
| Cooling Row Diameter | 3/4" |
| Core Dimension | 17" x 26-1/4" |
| Core Thickness | 1.57" |
| Emission Code | 5 |
| Flow Style | Cross Flow |
| Hose Location Inlet | Driver |
| Hose Location Outlet | Passenger |
| Inlet Diameter | 1-3/8 in. |
| Inlet Location | Driver |
| Inlet Size | 1-3/8 in. |
| Mounting Type | Saddle Mount |
| Outlet Diameter | 1-1/2 in. |
| Outlet Location | Passenger |
| Outlet Size | 1-1/2 in. |
| Overall Dimension | 18-3/4" x 32-1/4" |
| Part Type | Radiator |
| Product Type | Radiator |
| Row Quantity | 2 |
| Rows | 2, 2 |
| Transcooler Provision | 1/2-20 Straight Thread G 1/4 |
| Transmission Oil Cooler Included | 1/2-20 Straight Thread G 1/4 |
