Vintage Air Gen 5 Magnum™ Evaporator Kit 675100

Vintage Air Gen 5 Magnum™ Evaporator Kit 675100
Vintage Air Gen 5 Magnum™ Evaporator Kit 675100Vintage Air Gen 5 Magnum™ Evaporator Kit 675100
$1,931.99 ea
NEWARRIVING SOONEstimated Ship Date 11/19/2025 (If Ordered Today)
Model: 5004956
IMPORTANT: Electrical items are covered by a 30 day EXCHANGE ONLY WARRANTY. There are no returns or refunds on such items.
This product has universal fitment. Please check description and specifications to ensure that this product will work with your vehicle.
STANDARD
DELIVERY
STORE PICKUP
[More Info]
The Gen 5 is Vintage Air's most powerful and intelligent climate control system. The Gen 5 uses an exclusive fully electronic microprocessor control system that eliminates cables or vacuum connections. Separate high-capacity copper parallel-flow heat coil and aluminum plate-and fin-cooling coils provide outstanding performance and instant temperature adjustments.

Additional features include variable blower speed and dash/floor/defrost blend.

**The Gen 5 Magnumâ„¢ kit includes the evaporator unit and mounting brackets a wiring harness an electric servo heater control valve duct hoses a drain kit and detailed installation instructions.

Bullet Points
Engineered to cool your vehicle faster than ever
Improved diagnostics and advanced systematic fail safes
Multiple mounting options for an easier installation
Rubber well-nut mounting points for improved NVH isolation
Separate high-capacity A/C and heater coils with blend air door for rapid vent temperature adjustment
OEM block-type expansion valve
Injection molded case for optimal precision, strength and quality
Injection molded blend air doors with integral rubber seals
Removable access covers for coil service
Interchangeable defrost and floor heat plenums for increased mounting flexability
Powder coated steel mounting brackets

Application Note

NOTES:
1. Controls are ordered separately. Be sure to check out our assortment of control panel options.
2. Under-hood components such as the compressor, compressor mounting bracket, condenser, hose kit, drier, and optional upgrades are ordered separately.
About Vintage Air

Vintage Air, founded by Jack Chisenhall in 1976, is a San Antonio, Texas-based company specializing in the design and manufacture of high-performance aftermarket air conditioning systems for classic and late-model cars and trucks. Recognized as pioneers in the industry, they have been instrumental in developing climate control solutions tailored to the unique needs of automotive enthusiasts.

The company's product lineup includes the SureFit Series, which offers complete bolt-in, vehicle-specific climate control systems for classic and late-model muscle cars, restomods, and trucks. These systems are designed for easy installation, utilizing most of the factory sheet metal and body features. Additionally, Vintage Air provides the Builder Series, allowing customers to create custom climate control systems by selecting from various evaporators, controls, louvers, and accessories to best fit their specific build requirements.

Over the years, Vintage Air has earned a reputation for innovation and quality, becoming a trusted name among automotive enthusiasts and professional builders alike. Their commitment to excellence is evident in their comprehensive product offerings and dedication to customer satisfaction.

Downloads:

Download Name File Size
install_instructions_12316510.pdf4.89MB
